Product Features
01
Efficient No-Till Operation
With 220 kg unit downforce and 420 mm dual-disc openers, it achieves a residue clearance rate of over 95%.
Completes the full process of trenching, seeding, and covering in a single pass, boosting efficiency by 40%.
02
Intelligent Precision Seeding
Vacuum seed meters ensure plant spacing error ≤ 1 cm, with a missed seeding rate < 0.8%.
Equipped with a real-time monitoring system that triggers an alert within 0.5 seconds of detecting anomalies, achieving a seeding qualification rate > 99%.
03
Flexible Adaptability
Modular design supports fast switching between crops like corn and soybeans.
Stepless row spacing adjustment from 400–700 mm, meeting the needs of conservation tillage and dense planting.
04
Hybrid power mode with electric drive for both movement and operation.
Military-Grade Durability
304 stainless steel fertilizer box offers excellent corrosion resistance;
Manganese steel dual-beam frame increases load capacity by 50%;
Anti-wrapping PTO shaft achieves 96% transmission efficiency and a service life of over 8,000 mu.
product description
| Item Name | Matching Power | Overall Dimensions | Operating Speed Range | Row Spacing | Number of Rows | Seed/Fertilizer Box Capacity |
| Unit | kW | mm | km/h | mm | line | L |
| Model Y-2 | 25.8~47.8 | 3415x2140x1680 | 8~10 | 400~700 | 2 | 33x2/360 |
| Model Y-4 | 44.1-58.8 | 3415x3110x1680 | 8~10 | 400~700 | 4 | 33x4/360x2 |
| Model Y-5 | 58.8~95.6 | 3330x3100x1680 | 8~10 | 400~700 | 5 | 33x5/360x2 |
| Model Y-6 | 102.9~169.5 | 3910x4100x1800 | 8~10 | 400~700 | 6 | 33x6/480x2 |
| Model Y-8 | 147~250 | 3910x5500x1800 | 8~10 | 400~700 | 8 | 33x8/670x2 |
