Tracked Autonomous Spraying Robot
Performance characteristics
High-Efficiency Spraying System
Precision Nozzle Control
Stable Driving System
Full Remote Control Operation
Modular Operation Capability
RTK Expansion Support
Product Features
01
Air-assisted atomization delivers fine and uniform droplets, effectively improving chemical adhesion while reducing drift and waste.
02
Independent nozzle on/off control; adjustable spray angle and spray volume to meet different crop and application requirements.
03
Extended crawler track design with low ground pressure and excellent anti-slip performance, suitable for soft and wet ground conditions.
04
Supports stepless speed control and zero-turn steering with automatic braking; remote control range exceeds 200 meters.
05
Spraying and mowing modules adopt a modular design, supporting quick replacement and functional expansion for multi-purpose operation.
06
Optional high-precision RTK positioning system available to support path planning and precision operations.
product specs
| Item Name | Unit | Details |
| Model | / | PKE-260 |
| Dimensions | mm | 1850*1060*1000 |
| Item Name | Unit | Details |
| Model | / | PKE-260 |
| Dimensions | mm | 1850*1060*1000 |
| Tank Capacity | L | 270L |
| Horizontal Range / Spray Width | mm | 12000 (Full Machine Spray Width) |
| Total Weight | kg | 380 |
| Structure Type | / | Self-Propelled |
| Working Pressure | MPa | 2.5 |
| Travel Speed | m/min | 0–70 |
| Power Supply Voltage | V | 48 |
| Drive Type | / | Tracked Drive |
| Steering Type | / | Differential Steering |
| Fan Speed | r/min | 3000 |
| Fan Power | kW | 1 |
| Walking Power | kW *qty | 1.5*2 |
| Water Pump Power | kW | 1.1 |
| Minimum Ground Clearance | mm | 180 |
| Track Width | mm | 150 |
| Track Pitch | mm | 72 |
| Number of Track Links | / | 37 |
| Battery Type | / | Lithium Iron Phosphate |
| Battery Nominal Voltage | V | 48 |
| Battery Capacity | Ah | 20 |
